FRA 3 Data Center
Frankfurt am Main, Germany
Construction of the FRA 3 Data Center, consisting of a main building and a substation. The main building comprises three upper floors and two basement floors. The upper floors (levels 0 to 2) contain the server rooms (data halls) and an office block while the basement floors are mainly used for technical and storage rooms.
Upon commencement of its operations, the Data Center is anticipated to generate 30 to 36MW of IT power over its nine data halls.
Upon commencement of its operations, the Data Center is anticipated to generate 30 to 36MW of IT power over its nine data halls.
The entire object comprises approx. 29.900 sqm gross floor area.
Services:
- Structural Design, work stage 3/4-5 (LP3/4-5)
- Workshop Design for Precast Elements
- As-built drawings
- BIM Services
- Workshop Design for Precast Elements
- As-built drawings
- BIM Services
Extension of Munich Metro Line U5 to Pasing
MUNICH, GERMANY
The city of Munich is expanding the underground network in the west of Munich and by extending the U5 line from the existing Laimer Platz station to Pasing. The new underground line has a length of around 3.8 kilometres and is being built in two sections. Construction lot 1 comprises the section between the existing Laimer Platz station in the east and the new Willibaldstraße station to be built in the west. The underground railway construction work in lot 1 is carried out using the diaphragm wall/cover construction method.
The total length of the construction is approx. 1.000 meters.
(Photo: Münchner Verkehrsgesellschaft)
SERVICES:
- Structural Design, work stage 5 (LP5) for tunnel block 01 bis 103 incl. interior fit-out, accesses, stairs, platforms, and diaphragm walls
- As-built Drawings
- BIM Services
New construction of the S-Bahn S21 in Berlin
Berlin, Germany
The S-Bahn S21 project in Berlin involves the construction of an 800-meter-long railway line, which includes a 609m long tunnel and a 191m long trough. The line creates a north-south connection, passing through key interchange stations such as Hauptbahnhof, Potsdamer Platz, and Gesundbrunnen.
The project section that gbc engineers works on is built using open construction methods. The station slab is constructed with cut-and method (supporting structure with subsequent slab extension)
Photos: Ed. Züblin AG / Implenia AG
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
FRA31 Data Center
Raunheim, Germany
The project is a new construction of a Vantage data center FRA31 with office and logistic areas, a parking facility with 56 as well as 6 underground fuel tanks, 2 above-ground water tanks, a pump house and a fencing system.
The FRA 31 structure will serve as a 32 MW-Data Center, consisting of 1 basement, 1 ground floor, 2 upper floors and 1 roof level and has ground plan dimensions are approx. 101m x 82m. The building comprises the lobby entry, customer area, customer office and storage area and a loading bay.
The entire object comprises approx. 35.700 sqm gross floor area.
The entire object comprises approx. 35.700 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
- Workshop Design for Precast Elements
- BIM Services
Geberit Lichtenstein
St. Egidien, Germany
The building project involves the construction of a new sprinkler control center and two single-story halls (H3 and H4) with covered outdoor storage for production and logistics directly adjacent to an existing hall (H1). Hall H3 is separated from halls H1 and H4 by movement joints in the roof level. The entire object comprises approx. 11.800 sqm gross floor area.
The individual partial buildings have the following dimensions:
The individual partial buildings have the following dimensions:
- Hall 3: 197.91 m x 35.00 m x 10.00 m
- Hall 4: 75.6 m x 40.7 m x 10.00 m
- Sprinkler control center: 9.70 m x 9.70 m x 3.50 m
Photo: rewa Planungsgesellschaft mbH
Photo: rewa Planungsgesellschaft mbH
Services:
- Structural Design, work stage 2-6 (LP2-6)
- Workshop Design for Precast Elements
- BIM Services
- Workshop Design for Precast Elements
- BIM Services
BER14 Data Center
Berlin, Germany
The new construction of a low-rise data center from Vantage Data Centers.
The BER14 building is approx. 82.1 meters long, 31 meters wide, and 20 meters high, encompassing a yard, a ground floor, a first floor, and a roof floor, with each floor standing roughly 6 meters tall.
The entire object comprises approx. 12.000 sqm gross floor area.
The entire object comprises approx. 12.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- Workshop Design for Precast Elements
- BIM Services
Residential and Commercial Building Glatter Aal
Rostock, Germany
New construction of a residential and commercial building with underground car park in Rostock.
The project focuses on construction site B, which is divided into 4 parts:
- Part A is a residential section and comprises a ground floor and 6 upper floors (16.280 sqm GFA).
- Part B is a hotel and comprises a basement, a ground floor and 6 upper floors (4.830 sqm GFA).
- Part C is an underground car park - basement with 3 parking levels (11.160 sqm GFA).
- Part D is the foundation.
The entire property has a gross floor area of approx. 33.000 sqm.
(Picture: McGrath Group Properties)
(Picture: McGrath Group Properties)
Services:
- Civil and Structural Design, work stage 4-5 (LP4-5)
- BIM Services
Steimker Garten 4.0 and 4.1
Wolfsburg, Germany
Construction of a new residential and commercial building, consisting of two buildings in the project Steimker Garten:
- Steimker Garten 4.0: The building has 36 residential units and an underground car park, with 1 basement, 1 first floor, 4 upper floors, and 1 mezzanine floor. The total gross floor area of this building is apprx. 1.955 sqm.
- Steimker Garten 4.0: The building has 36 residential units and an underground car park, with 1 basement, 1 first floor, 4 upper floors, and 1 mezzanine floor. The total gross floor area of this building is apprx. 1.955 sqm.
- Steimker Garten 4.1: The building has 152 residential units and an underground car park, with 2 basements, 1 first floor, 4 upper floors, and 2 mezzanine floors. The total gross floor area of this building is apprx. 23.390 sqm.
(Photo: Meyer Projekt)
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
CCNO Ludwigsfelde
Ludwigsfelde, Germany
Chefs Culinar wants to create more than 450 new jobs on a 15-hectare site in the Eichspitze industrial park in Ludwigsfelde. The planned property is the new construction of a wholesale warehouse, consisting of a production hall, an administration building, a dry warehouse, a deep-freeze warehouse, a technological building, a goods receiving department, and a warehouse for empties.
The entire object comprises approx. 63.000 sqm gross floor area.
The entire object comprises approx. 63.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-5 (LP4-5)
- Workshop Design for Precast Elements
- BIM Services
Haldensprung bridge
Huckarde, Germany
The Haldensprung Bridge is part of the International Garden Exhibition (IGA - Internationalen Gartenausstellung). The pedestrian and bicycle bridge with a total length of almost 160 meters will connect the neighborhoods of Huckarde and Deusen. The bridge is built as a barrier-free steel truss bridge with adjoining ramps and stairs. The system is designed as an integral superstructure.
(Photo: bbz landscape architects berlin gmbh)
Services:
- Structural Design, work stage 3-5 (LP3-5), including steel works, excavation, and foundation drawings
- BIM Services
TESLA Gigafactory, Berlin-Brandenburg
Grünheide, Germany
The object is the new construction of the water treatment (WWT), a wasteyard and a stamping facility of the Tesla Gigafactory Berlin-Brandenburg.
The entire object approx. 34.000 sqm gross floor area. Specifically, The WWT building comprises a ground floor and an upper floor with a GFA of 7.600 sqm. The wasteyard is a single story building with 7.900 sqm GFA. The stamping is a 18.500 sqm building.
The entire object approx. 34.000 sqm gross floor area. Specifically, The WWT building comprises a ground floor and an upper floor with a GFA of 7.600 sqm. The wasteyard is a single story building with 7.900 sqm GFA. The stamping is a 18.500 sqm building.
Services
- Structural Design, work stage 1-6 (LP1-6)
- Steel Structure Design
- Workshop Design for Precast Elements
- BIM Services
- BIM Services
FR10 Data Center
Frankfurt, Germany
The project involves the construction of a new data center with an adjoining office/ storage area, a generator building and the construction of 23 parking spaces. The walls will be approximately 5m high with continuity reinforcement at intermediate levels. The buildings will be constructed 1 level at a time. The entire building consists of:
- The main building has a 3-storey non-roofed industrial building and an adjoining 4-storey office building in reinforced concrete and ground plan dimensions of approx. 55m x 61m. Above the data center is a 2-storey technical platform in steel construction.
- The generator building is a 3-storey building for emergency power generators and pump rooms with no basement in reinforced concrete. A technical platform in steel construction is planned on the roof.
- Adjoining tank facilities for diesel and sprinkler water
The foundation of entire building is built on an elastically bedded floor slab.
The entire object comprises approx. 16.880 sqm gross floor area.
The entire object comprises approx. 16.880 sqm gross floor area.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
BER22 Data Center
Berlin, Germany
The object to be designed is a new construction a low-rise data center from Vantage Data Centers. The low-rise design consists of a data center building with an adjacent yard and is located next to BER21. The scope of this offer is the structure of the BER22. The building is about 82 m long, 79 m wide and 20 m high. The building consists of a ground floor, first floor and roof floor. Each floor measures about 6 m high. The main load bearing structure - floors, beams, columns and walls - is made of precast concrete elements. The foundation consists of single and strip foundations. Equipment supporting structures, e.g. the roof platform, are made from structural steel.
The entire object comprises approx.18.000 sqm gross floor area.
The entire object comprises approx.18.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
New thermal power plant in Leipzig Süd
LEIPZIG, GERMANY
The planning of the new thermal power plant in Leipzig Süd, Germany (HKW Leipzig Süd). This project includes:
1. A power station building (55.8m x 40.3m)
2. A gas system building (31.8m x 24.0m)
3. A pump hall (42.5m x 24.5m).
The entire object comprises approx. 17.500 sqm gross floor area.
Photo: André Kempner/ Gaskraftwerk Süd
Photo: André Kempner/ Gaskraftwerk Süd
SERVICES:
- Structural Design, work stage 4-5 (LP4-5)
- Workshop Design for Precast Elements
- BIM Services
FR13 Data Center
Frankfurt, Germany
The object is a new construction of a low-rise data center from Vantage Data Centers. The low-rise design consists of a data center featuring several buildings. The scope of this project is the structure of FR13. The object FR13 is about 76 m long, 32 m wide and a maximum of 27m high.
The entire object comprises approx. 13.900 sqm gross floor area.
The entire object comprises approx. 13.900 sqm gross floor area.
Services
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
BER21 Data Center
Mittenwalde, Berlin-Brandenburg, Germany
Structural detailed design for the BER21 data center in Mittenwalde, Berlin. The low-rise design consists of two data centers BER21 A1 and A2. The data center campus is a 4.5 hectare site with a master plan for the construction of two buildings.
The entire object comprises approx. 14.900 sqm gross floor area.
The entire object comprises approx. 14.900 sqm gross floor area.
Services
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
BER13 Data Center
Uferring, Ludwigsfelde, Berlin, Germany
Structural detailed design for the BER13 data center in Uferring, Ludwigsfelde, Berlin. The object is a new low-rise data center construction by Vantage Data Centers. The low-rise design consists of a data center, referred to as BER13 in this example, and a yard.
The entire object comprises approx. 14.900 sqm gross floor area.
The entire object comprises approx. 14.900 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
New construction of a Warehouse in Oederan
Oederan, Germany
Planning for the new construction of a warehouse in Oederan, Germany. The building has two stories and a social wing. The entire property has external dimensions of approx. 100.0m x 48.5m and the entire object comprises approx. 4.850 sqm gross floor area.
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
Extension of Bakery Reimann
Dresden, Germany
Planning for the extension of the order picking place and warehouse of a bakery in Dresden, Germany. The building comprises of a ground floor, an upper floor, and an attic. The entire property has a GFA of around 5.200 square meters
Photo: Architecture Gallery Greven
Photo: Architecture Gallery Greven
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
New construction of bakery in Chemnitz
Chemnitz, Germany
The planning for the new construction of a bakery in Chemnitz, Germany. The bakery has the dimensions of approx. 61m x 49m, and the additional warehouse has the size of approx. 24m x 17m. The bakery/storage area is single-story, while other areas (office + social) are executed as two-story.
Photo: Schäfers Backstube GmbH
Photo: Schäfers Backstube GmbH
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
New Headquarter Building of the Lower Saxony Medical Association
Hannover, Germany
gbc engineers participated in the planning for the new headquarter building of the Lower Saxony Medical Association (Ärztekammer Niedersachsen). The building is located in Hannover, Germany. It has GFA of approx. 12.500 sqm and is divided into 02 parts due to different uses: west wing and east wing. When finished in 2021, the building will be used as offices, seminar and conference rooms. For this project, gbc engineers provided structural detailed design service.
Photo: Michael Thomas/ Theda Eggers/ Bärbel Miemietz
Photo: Michael Thomas/ Theda Eggers/ Bärbel Miemietz
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
For a Child's Smile - PSE
Phnom Penh, Cambodia
The French Non-Governmental Organization “pour un sourire d’enfant” (PSE) - For a Child's Smile is currently constructing new school buildings. After the completion of construction, the school will ensure thousands of students from poor background in Cambodia the possibility to access to education in proper and standard environment.
The entire object comprises approx. 3.600 sqm gross floor area.
The entire object comprises approx. 3.600 sqm gross floor area.
Services:
- Structural Engineering Design
- Author Supervision during Construction
Phnom Penh International Airport
Phnom Penh, Cambodia
Phnom Penh International Airport, the busiest and largest airport in Cambodia, went through a renovation. As a part of this renovation, a Solar PV System was installed on existing roofs of the airport's buildings. Participating in this project, gbc engineers provided Roof Structural Survey, as well as Structural Analysis and Assessment Report for the terminal and ground handling building.
The entire object comprises approx. 14.604 sqm gross floor area.
The entire object comprises approx. 14.604 sqm gross floor area.
Services:
- Roof Structural Survey
- Structural Analysis and Assessment Report
Royal Train Square
Phnom Penh, Cambodia
Phnom Penh’s Royal Railway Station was built in 1930s during the French Colonial period and made of reinforced concreted structures with western architecture, and it has become an iconic spot in the city. Our client, Train Square Co., Ltd., is conducting a renovation to turn this antique building into a modern entertainment centre and hangout spot named “Royal Train Square”. It will include shops, cafes, restaurants, banks, offices and exhibition space.
The entire object comprises approx. 5.095 sqm gross floor area.
The entire object comprises approx. 5.095 sqm gross floor area.
Services:
- Building investigation and Assessment,
- Structural Strengthening Design,
- Author Supervision during Construction
Khmer Beverages (KHB) factory
Phnom Penh, Cambodia
gbc engineers Cambodia has been chosen to perform structural survey and assessment of Khmer Beverages (KHB) factory in Phnom Penh.
Khmer Beverages is the leading producer of alcoholic and non-alcoholic drinks in Cambodia. The company plans to install solar panels on the existing building roofs of this facility. The installation is planned on 7 buildings, divided in 5 steel superstructures supported by reinforced concrete foundation and 2 reinforced concrete structures, with a total surface of approx. 40.000 sqm
Khmer Beverages is the leading producer of alcoholic and non-alcoholic drinks in Cambodia. The company plans to install solar panels on the existing building roofs of this facility. The installation is planned on 7 buildings, divided in 5 steel superstructures supported by reinforced concrete foundation and 2 reinforced concrete structures, with a total surface of approx. 40.000 sqm
Services:
- Roof Structural Review
- Structural Survey and Assessment
- Structural Survey and Assessment
Residential Complex on Alfred-Leikam Street
Waiblingen, Germany
New construction of a residential complex on Alfred-Leikam Street in Waiblingen, Germany. This project consists of 8 residential buildings with 38 condominiums, 46 rental apartments, a daycare center and a shared underground car park. The buildings (House 1 - House 8) have 4 floors. House 1 - House 3 each also have an attic. Total GFA is 15.000 sqm.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
DETECH Tower
Hanoi, Vietnam
gbc engineers is participating in the design of the DETECH Tower Project as a structural consultant. The Project is located in Hanoi, Vietnam.
gbc engineers will provide structural engineering design services for the tower D2, in three stages: Basic Design, Technical Design and Detailed Design. This tower’s site area is around 5.335 sqm and GFA is approx. 91.000 sqm, featuring 33 storeys and 4 basement. When completed, the building will be used as office and hotel.
gbc engineers will provide structural engineering design services for the tower D2, in three stages: Basic Design, Technical Design and Detailed Design. This tower’s site area is around 5.335 sqm and GFA is approx. 91.000 sqm, featuring 33 storeys and 4 basement. When completed, the building will be used as office and hotel.
Services:
- Structural Design services for the tower D2 in three stages: Basic Design, Technical Design and Detailed Design
- BIM Services
- BIM Services
Pepperl + Fuchs Greenfield Factory
Ho Chi Minh City, Vietnam
New construction of electronic sensors and components factory Pepperl+Fuchs (P+F). The project includes new warehouse, production facility, and multi storey motorbike parking. GFA is approx. 21.390 sqm.
Services:
Structural Design Review in compliance with Eurocode and Good Engineering Practice (GEP)
Le Mia Phnom Penh
Phnom Penh, Cambodia
Construction of the residential building “Le Mia” in Street 208, Phnom Penh, Cambodia. Le Mia project is a luxury apartment with 4 basements, 1 ground floor and 33 upper floors. Total construction area is approx. 21.380 sqm.
Services:
- Structural Design, work stage 1-6 (LP1-6)
- BIM Services
- BIM Services
Vattanac Capital Lifestyle Park
Phnom Penh, Cambodia
With GFA over 30.000 sqm featuring the garden on ground floor, Vattanac Capital Lifestyle Park will become one of the largest underground parking in Phnom Penh as well as in Cambodia.
Services:
- Structural Design Review
- Construction Drawings
Resort Development
Sihanoukville, Cambodia
Coastal integrated Resort Development in Sihanoukville, Cambodia hosting a mixed-use complex with hospitality, 3 to 5 star hotels, promenade & boardwalk and waste water treatment plan. The development includes a total area of 95.000 sqm GFA.
Services:
- Project Management
- Civil and Structural Conceptual Design
European Commission Headquarters Building - Jean Monnet II
Luxembourg
The new European Commission Headquarters Building in Luxembourg - Jean Monnet II is currently under construction. The project will be constructed in two phases, comprising a seven-storey building and a 90-meter-high office high-rise (23-storey tower) including 4 basement levels and a total of 190.500 sqm GFA. Soon, 3,600 staff members will work in a single complex of buildings. The architectural design of the building was entrusted to KSP Jürgen Engel Architekten who delivered an outstanding architectural design. The completion of the project is scheduled for late February 2024. gbc engineers is proud to take part in this unique project.
Picture: KSP Jürgen Engel Architekten/ Luxofluxo
Picture: KSP Jürgen Engel Architekten/ Luxofluxo
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
Paul Gerhardt Allee
Munich, Germany
New construction of the Paul-Gerhardt-Allee residential complex in 81245 Munich with approx. 37.420 sqm GFA. The residential complex consists of an underground garage, which functions as a courtyard (above the basement). There are 15 apartment buildings with different floors.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Sengelmannstraße
Hamburg, Germany
New construction of a residential and commercial complex in Sengelmannstraße, 22297 Hamburg, consists of 2 basements, 1 ground floor and 6 upper floors. The entire object comprises approx. 25.200 sqm GFA.
Services:
- Civil and Structural Design, work stage 5 (LP5)
- BIM Services
The Sun Avenue Residence
Ho Chi Minh City, Vietnam
The Sun Avenue apartment complex in Ho Chi Minh City, Vietnam consists of 8 residential high-rise towers. Each tower features 2 basements, 5 podium floors and 28-30 floors above ground. The entire project includes a total GFA of over 250.000 sqm.
Services:
- Structural Value Engineering Design
- Evaluation and Design of Alternative Cost-efficient Construction Methods, Using Hollow Core Slabs, Solid Flat Slabs and Prefabricated Staircases
Novotel Sihanoukville
Sihanoukville, Cambodia
New constructed hotel compound with 9 storey main building including one basement. The project has GFA of approximately 16.000 sqm.
Services:
- Structural Design Review
- Structural Value Engineering
- Civil and Structural Concept and Detailed design
- Construction Drawings
Harbor City Townhouses
Ho Chi Minh City, Vietnam
New residential project in district 8, Ho Chi Minh City, Vietnam.
Services:
- Conceptual Design Review
- Conceptual Development and Evaluation of Alternative Design
- Redesign from In-situ to Precast Elements to Optimize Construction Methods
- Conceptual Development and Evaluation of Alternative Design
- Redesign from In-situ to Precast Elements to Optimize Construction Methods
Sports and Events Hall (SVH) in Nürnberg
Nürnberg, Germany
New construction of a sports and events hall (SVH) in Nürnberg. The project consists of a sports hall with adjoining foyer and warehouse, as well as a 2-storey functional building with a training hall. The dimensions of the main sports hall are approximately 66m x 54m x 16m. The dimensions of the warehouse are approx. 12m x 54m x 6.6m, of the foyer approx. 12m x 54m x 7.6m and of the functional building with a training hall approx. 74m x 15mx 6.6m.
The entire object comprises approx. 25.000 sqm gross floor area.
The entire object comprises approx. 25.000 sqm gross floor area.
Services:
- Civil and Structural Design, work stage 1-6 (LP1-6)
- BIM Services
- BIM Services
Garz & Fricke Headquarter
Hamburg, Germany
The new HQ of Garz & Fricke in Hamburg Harburg will be used as the center for Research, Development and Production. It includes a factory hall with assembly and laboratory workstations, as well as storage area and an administration building with office and laboratory use. GFA: usable area of approx. 12,826 sqm
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Complex Office & Apartment Building
Dong Nai Province, Vietnam
Complex office and apartment building with a total floor area of 22,250 sqm. The building complex consists of 01 commercial, 01 office and 03 apartment block buildings featuring 2 basements and 15 floors.
Services:
- Civil and Structural Design, work stage 3 (LP3)
- BIM Services
- BIM Services
NEUES PRORA - Block I
Prora on Rügen, Germany
The refurbishment of a heritage building complex dated 1937 is currently ongoing. The design plan includes a mixture of residential apartments and hotel rooms. A total of 280 units are being constructed for this project.
Photo: TEUFFEL ENGINEERING CONSULTANTS
Photo: TEUFFEL ENGINEERING CONSULTANTS
Services:
- Structural Design, work stage 4-5 (LP4-5)
- BIM Services
Apartment Complex
Chemnitz, Germany
New apartment building complex located in Chemnitz, Germany consisting of 3 individual buildings with a total of 8,000 sqm GFA. In cooperation with iproplan® Planungsgesellschaft mbH, Germany.
Services:
- Civil and Structural Design, work stage 5 (LP5)
- Workshop Design for Steel Structure
- BIM Services
Residential Complex
Harburg, Germany
Residential complex consisting of 310 residential units. 21 five-storey buildings partly with basement. The project covers a total area of 38,250 sqm GFA.
Services:
- Civil and Structural Design, work stage 4-5
- BIM Services
- BIM Services
Business and Apartment Building
Dresden, Germany
Business and apartment building with a total floor area of 23,500 sqm. The building complex consists of eight floors with two parking basements. In cooperation with iproplan® Planungsgesellschaft mbH, Germany.
Services:
- Civil and Structural Design, work stage 5 (LP5)
- BIM Services
Total Cambodia - Odem Warehouse Expansion
Phnom Penh, Cambodia
Expansion of the TOTAL Cambodia S.A. Warehouse facility in Phnom Penh Odem, Cambodia.
The entire object comprises approx. 1.880 sqm gross floor area.
The entire object comprises approx. 1.880 sqm gross floor area.
Services:
- Topographic Survey and Geotechnical Investigations,
- Architectural, MEP, Civil and Structural Engineering Design
- Feasibility Studies, Concept and Detailed Design incl. Tendering
Mercedes-Benz Autohaus
Phnom Penh, Cambodia
Mercedes-Benz Autohaus consists of a 2-storey showroom building with approx. 5.100 sqm GFA. The structure of the building features wide span RC roof slabs on steel sheets supported by slender steel columns.
Services:
- Civil and Structural Concept Design
- BIM Services
- BIM Services
Turmstraße 65
Berlin, Germany
The project is located at Turmstrasse 65 / Gotzkowskistrasse 1, 10551 Berlin Moabit. This corner building in Tiergarten district, plot 45, land parcel 149 has a total size of 422 m2. The building has a commercial area i.e., pharmacy and shops on the ground floor. The upper floors shall be used as clinic and office area. The planned GFA is approximately 3.000 sqm in total.
Photo: Deutsches Architekturforum
Photo: Deutsches Architekturforum
Services:
- Civil and Structural Design, work stage 2-6 (LP2-6)
- BIM Services
ChildCare Clinic in Strausberg
Strausberg, Germany
A new childcare clinic in Amselweg in Strausberg, Germany with 57 primary patient beds, 120 secondary care units as well as various office and treatment rooms. In addition, there is a sport hall with swimming pool. The clinic consists of six buildings with total GFA of approx. 22.500 sqm.
Services:
- Structural Design, work stage 2-5 (LP2-5)
- BIM Services
Zollhof Wentorf
Wentorf near Hamburg, Germany
Residential and Commercial building with parking garage in the center of Wentorf. The 3 - 4 - storey building responds not only the available urban development stock but also services as the link between the old and new center of Wentorf. GFA: 10.060 sqm
Photo: Susanne Tamm
Photo: Susanne Tamm
Services:
- Structural Design, work stage 1-6 (LP1-6)
- BIM Services
Stallschreiber Quartier
Berlin, Germany
A complex of residential buildings at Stallschreiber Street, Berlin. The building complex consists of four buildings with one Underground floor used as Underground parking with a total of approx. 43.400 sqm.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Allianz Headquarter Berlin
Berlin, Germany
Construction of the Allianz Headquarter in Berlin, a complex made of 3 administrative/ office-buildings with a total of 75.000 sqm GFA
Services:
- Civil and Structural Detailed Design
- BIM Services
Siemens Campus Erlangen
Construction of the new Siemens Campus in Erlangen (Module 1). The modern campus will be constructed on an area of approx. 54 hectares with a total of 7 modules. As part of module 1, 8 service- and research-buildings are built. Each building consists of a ground floor and 5-6 upper floors. As part of the project, 6 buildings with a total of approx. 90.000 sqm GFA are built.
Photo: Firmgenruppe Max Bögl / Siemens AG
Photo: Firmgenruppe Max Bögl / Siemens AG
Services:
- Structural Design, work stage 4-5 (LP4-5)
- BIM Services
Baakenhafen BF 99
Hamburg, Germany
The residential building complex Baakenhafen 99 at Hamburg HafenCity consists of three 8-storey buildings and a large car parking basement floor. The total GFA counts approx. 22.330 sqm.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Dreiländer Galerie
Weil am Rhein, Germany
The Dreiländer Galerie is a new shopping centre with approx. 75.000 sqm GFA (16.500 sqm shopping area) in the German town of Weil am Rhein, close to the meeting point of the French and Swiss borders with Germany. The project containing three levels of retail and three levels of underground parking for 586 cars, as well as a kindergarten on the roof, it is intended to attract visitors from across the Swiss border in Basel, aided by a new tram line from there complete with turning loop. Completion of construction works is estimated end of 2020.
(Photo: Chapman Taylor)
(Photo: Chapman Taylor)
Services:
- Structural Design, work stage 4-6 (LP4-6)
- BIM Services
Henschelstraße
Munich, Germany
New construction of a new residential complex in Henschelstrasse, 81249 Munich-Lochhausen. The entire project comprises 20 buildings with approx. 52.981 sqm GFA. gbc-engineers performed the services for houses from 1 to 5 and from 12 to 20.
Services:
- Civil and Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
Residential Building Complex Lindenhof
Berlin, Germany
New construction of the Residential Building complex “Lindenhof” in Berlin with total 585 apartments. Gbc engineers performed the services in building 44, 51 and 52 with a total of approx. 18.000 sqm GFA.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Residential Building Complex Lessinghöfe
Neu Wulmstorf, Germany
New construction of the residential building complex Lessinghöfe in Neu Wulmstorf with approx. 400 apartments. The project consists of approx. 20,000 sqm GFA.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
Residential Apartment Complex
Leipzig-Marienbrunn, Germany
Newly constructed residential building complex with 95 apartments and a GFA of approx. 7.900 sqm. Construction time was reduced by using prefabricated elements.
Services:
- Structural Feasibility Studies
- Value Engineering Design
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
Roof Extensions of Residential Buildings
Berlin-Köpenick, Kiefholzstrasse, Germany
Newly constructed loft on existing heritage buildings in Berlin. Three apartments with a total living area of 300 sqm.
Services:
- Schematic Design
- Detailed Design
- Detailed Design
- Site Supervision
Apartment Building Lützowstrasse
Berlin-Tiergarten, Lützowstrasse, Germany
Newly constructed complex residential building ensemble consisting of two buildings with 24 apartments, a basement parking area and a GFA of approx. 5.800 sqm. Building one and the attached garden house are interconnected and have a total of 7 stories. Building two is 8 stories high.
Services:
- Civil and Structural Concept, Schematic and Detailed Design
- Author Supervision during Constuction
Extension and Refurbishment of Apartment Buildings
Berlin-Friedrichshain, Frankfurter Alle, Germany
Extensive refurbishment of a Berlin heritage building complex located at the well-known Frankfurter Allee. The project volume covered 250 apartments in which many apartments were connected.
Services:
Structural Redesign Consultancy, including provision of analysis and detailed construction drawings.
Diamond Apartment Building
Phnom Penh, Cambodia
21-storey apartment building with approx. 24.000 sqm GFA and two basements
Services:
- Civil and Structural Feasibility Studies
- Civil and Structural Concept Design
New constructed Office Building
Düsseldorf, Germany
New constructed office building with a total GFA of approx. 6.000 sqm. The building features two parking basements.
Services:
- Civil and Structural Consulting Services
- Value Engineering Design and Cost Optimization
- Development of Construction Documents
Apartment Complex Wilmersdorf
Berlin-Wilmersdorf, Germany
Newly constructed residential building complex with 35 apartments and a GFA of approx. 4.800 sqm
Services:
- Civil and Structural Schematic Design
- Civil and Structural Detailed Design
Residence 90 Villa
Phnom Penh, Cambodia
Residence 90 - Villa Plot 56, 57. Each villa got in total approx. 600 sqm GFA and three storeys
Services:
- Value Engineering Design
- Structural Concept Design
- Structural Detailed Design
Prek Leap Villa
Phnom Penh, Cambodia
Residence Villa with Guest waiting house, maids and bodyguards house, swimming pool, guardhouses, pump room and fence wall GPA: approx. 5.000 sqm
Services:
Civil and Structural Detailed Design
Entrance bridge of Terminal 3 at Frankfurt Airport
Frankfurt Am Main, Germany
The new Terminal 3 building is to be built in the south of Frankfurt Airport to handle passenger traffic. The project consists of the access bridge at Frankfurt Airport Terminal 3, based on foundations, which in turn are supported by drilled piles.
The entire object comprises approx. 14.475 sqm gross floor area.
Photo: Jakob Wert/ Frankfurt Airport
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Railway Tunnel Stuttgart 21
Stuttgart, Germany
The railway and urban development project Stuttgart 21 in Germany is one of the largest and most complex infrastructure projects within the framework of the Trans-European Networks. Its core is a new Stuttgart Hauptbahnhof, among some 57 kilometres of new railways, including over 30 kilometres of tunnels and 25 kilometres of high-speed lines, comprising total costs estimated at 6.5 billion euros.
gbc engineers are proud to take part in the structural detailed design of the Fildertunnel and the Tunnel Ober- und Untertürkheim.
Photo: Eisenbahn.tv/ mplus-management.de/ NEREA LAKUNTZA
gbc engineers are proud to take part in the structural detailed design of the Fildertunnel and the Tunnel Ober- und Untertürkheim.
Photo: Eisenbahn.tv/ mplus-management.de/ NEREA LAKUNTZA
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
- BIM Services
Bridge HEM 10+13
Hannover, Germany
Within the scope of the new construction project of the bypass Hemmingen (B3, Hannover region, Germany), two sub-projects in the Bockstraße (HEM 10) and Pattenser Feldweg (HEM13) were designed by gbc engineers.
The federal highway 3 connects the middle centers Alfeld and Einbeck in South Saxony, as well as in connection with the federal highway 240 and 64, it connects the area Holzminden / Höxter with the provincial capital and the upper center of Hannover. The B3 has an important function in commercial traffic. As a gateway to the state capital of Hannover, it also services an important role in commuter traffic.
HEM 10: Overpass bridge at Bockstraße, east of the county road 225 (Stadtweg / Sohlkamp) between Devese, Ohlandorf and Arnum. Span 32.00 m, width 6.00 m
HEM 13: Overpass bridge at Pettenser Feldweg, west of B2 between Arnum and Patternsen. Span 30.50 m, width 6.00 m
Services:
- Structural Design Work Stage 5 acc. to German HOAI
- BIM Services
Railway Tunnel Gateway Gardens
Frankfurt, Germany
The new S-Bahn connection Gateway Gardens includes the relocation of the route between Frankfurt Stadium and Frankfurt Airport Regional Station as well as the construction of the new Gateway Gardens traffic station. The new line is divided into 16 construction phases and comprises a tunnel length of approx. 2,000 m, consisting of a rectangular tunnel profile. The order also includes several station structures.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
Apartment Complex Stuttgart
Renningen near Stuttgart, Germany
New apartment building complex located in Stuttgart, Germany consisting of 4 individual buildings with a total of 7.000 sqm GFA. All buildings are connected by an underground parking level.
Services:
Structural Design, work stage 5 (LP5)
New Apartment Building
Hamburg, Germany
Three new residential buildings that form a quiet residential complex with existing listed buildings. Consisting of 3 houses with 4 full floors and a basement with about 6.390 sqm GFA.
Services:
- Civil- and Structural Detailed Design
- Workshop Design for Steel Structure
Office Building Schiffbauergasse
Potsdam, Germany
New construction of a modern office building in the Schiffbauergasse in Potsdam-Germany, consisting of a ground floor and four upper floors with a total of approx. 5.000 sqm GFA.
Services:
- Structural Design, work stage 3-5 (LP3-5)
- BIM Services
Allianz “An der Alster“ Hamburg
Hamburg, Germany
New construction of Allianz office building “An der Alster 42“ in Hamburg with approx. 6.000 sqm GFA.
Services:
- Structural Design, work stage 4-5. (LP4-5)
- BIM Services
Railway Overpass BAB A5 - North West Center
Between Bad Homburg and Neu-Isenburg, Germany
An extensive construction of new tram route between Bad Homburg and Neu-Isenburg is planned as part of the project “Regionaltangente West”.
Overpass BAB A5, North West Center: 74m length; 9.02 m width; 667 sqm and 2 pieces.
Overpass BAB A5, North West Center: 74m length; 9.02 m width; 667 sqm and 2 pieces.
Services:
- Civil and Structural Concept Design, work stage 3 (LP3)
- BIM Services
Railway Overpass Eschborn, Lorscher Str
Between Bad Homburg and Neu-Isenburg, Germany
An extensive construction of new tram route between Bad Homburg and Neu-Isenburg is planned as part of the project “Regionaltangente West”.
Eschborn, overpass Lorscher Str.: 48.5m length, 9.32m width, 452 sqm and 2 pieces.
Eschborn, overpass Lorscher Str.: 48.5m length, 9.32m width, 452 sqm and 2 pieces.
Services:
- Civil and Structural Concept Design, work stage 3 (LP3)
- BIM Services
Railway Overpass Südallee (K162)
Between Bad Homburg and Neu-Isenburg, Germany
An extensive construction of new tram route between Bad Homburg and Neu-Isenburg is planned as part of the project “Regionaltangente West”.
Overpass Südallee (K162): 35.3m length; 9.14m width; 323 sqm and 2 pieces.
Overpass Südallee (K162): 35.3m length; 9.14m width; 323 sqm and 2 pieces.
Services:
- Civil and Structural Concept Design, work stage 3 (LP3)
- BIM Services
Railway Overpass Schwanheimer Knoten– North
Between Bad Homburg and Neu-Isenburg, Germany
An extensive construction of new tram route between Bad Homburg and Neu-Isenburg is planned as part of the project “Regionaltangente West”.
Railway overpasses Schwanheimer Knoten– North: 164.5m length; 9.14m width; 1.504 sqm; 6 pieces.
Railway overpasses Schwanheimer Knoten– North: 164.5m length; 9.14m width; 1.504 sqm; 6 pieces.
Services:
- Civil and Structural Concept Design, work stage 3 (LP3)
- BIM Services
Railway Overpass Schwanheimer Knoten– South
Between Bad Homburg and Neu-Isenburg, Germany
An extensive construction of new tram route between Bad Homburg and Neu-Isenburg is planned as part of the project “Regionaltangente West”.
Railway overpasses Schwanheimer Knoten– South: 129.3m length; 9.14m width; 1.182 sqm; 4 pieces.
Railway overpasses Schwanheimer Knoten– South: 129.3m length; 9.14m width; 1.182 sqm; 4 pieces.
Services:
- Civil and Structural Concept Design, work stage 3 (LP3)
- BIM Services
