Projects
INDUSTRIAL PROJECTS
Penta HAM01 Data Center
Hamburg, Germany
The new construction of a Penta data center is located at Obenhauptstraße in 22335 Hamburg. The data center consists of 1 basement, 1 ground floor and 2 upper floors.
The entire property comprises approx. 4.680 sqm of gross floor area.
Services:
- Structural Design, work stage 5 (LP5)
- Structural analysis and structural design, work stage 5 (LP5) for tower crane foundation and non-load bearing masonry.
- BIM Services
FR8.2 Data Center
Frankfurt, Germany
The new data center, FR8.2, is located at 139 Lärchenstrasse in Frankfurt, Germany, directly across from the existing FR4 data center. The main building, including the "back of house" area, measures approximately 86 meters in width and 150 meters in length, standing four stories tall.
The project is divided into three phases, covering the right, middle, and left sections. It specifically focuses on the middle section (Data Center FR8.2), which has dimensions of around 57.5 meters in width and 84.0 meters in length, spanning four stories.
The entire building comprises approximately 26,000 square meters of gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- Workshop Design for Precast Elements
- BIM Services
BER14 Data Center
Berlin, Germany
The new construction of a low-rise data center from Vantage Data Centers.
The BER14 building is apprx. 82.1 meters long, 31 meters wide, and 20 meters high, encompassing a yard, a ground floor, a first floor, and a roof floor, with each floor standing roughly 6 meters tall.
The entire object comprises approx. 12.000 sqm gross floor area.
The entire object comprises approx. 12.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- Workshop Design for Precast Elements
- BIM Services
FRA 3 Data Center
Frankfurt am Main, Germany
Construction of the FRA 3 Data Center, consiting of a main building and a substation. The main building comprises three upper floors and two basement floors. The upper floors (levels 0 to 2) contain the server rooms (data halls) and an office block while the basement floors are mainly used for technical and storage rooms.
Upon commencement of its operations, the Data Center is anticipated to generate 30 to 36MW of IT power over its nine data halls.
Upon commencement of its operations, the Data Center is anticipated to generate 30 to 36MW of IT power over its nine data halls.
The entire object comprises approx. 29.900 sqm gross floor area.
Services:
- Structural Design, work stage 3/4-5 (LP3/4-5)
- Workshop Design for Precast Elements
- As-built drawings
- BIM Services
- Workshop Design for Precast Elements
- As-built drawings
- BIM Services
FRA31 Data Center
Raunheim, Germany
The project is a new construction of a Vantage data center FRA31 with office and logistic areas, a parking facility with 56 as well as 6 underground fuel tanks, 2 above-ground water tanks, a pump house and a fencing system.
The FRA 31 structure will serve as a 32 MW-Data Center, consisting of 1 basement, 1 ground floor, 2 upper floors and 1 roof level and has ground plan dimensions are approx. 101m x 82m. The building comprises the lobby entry, customer area, customer office and storage area and a loading bay
The entire object comprises approx. 35.700 sqm gross floor area.
The entire object comprises approx. 35.700 sqm gross floor area.
SERVICES:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
- Workshop Design for Precast Elements
- BIM Services
Gerebit Lichtenstein
St. Egidien, Germany
The building project involves the construction of a new sprinkler control center and two single-story halls (H3 and H4) with covered outdoor storage for production and logistics directly adjacent to an existing hall (H1). Hall H3 is separated from halls H1 and H4 by movement joints in the roof level. The entire object comprises approx. 11.800 sqm gross floor area.
The individual partial buildings have the following dimensions:
The individual partial buildings have the following dimensions:
- Hall 3: 197.91 m x 35.00 m x 10.00 m
- Hall 4: 75.6 m x 40.7 m x 10.00 m
- Sprinkler control center: 9.70 m x 9.70 m x 3.50 m
Photo: rewa Planungsgesellschaft mbH
Services:
- Structural Design, work stage 2-6 (LP2-6)
- Workshop Design for Precast Elements
- BIM Services
- Workshop Design for Precast Elements
- BIM Services
CCNO Ludwigsfelde
Ludwigsfelde, Germany
Chefs Culinar wants to create more than 450 new jobs on a 15-hectare site in the Eichspitze industrial park in Ludwigsfelde. The planned property is the new construction of a wholesale warehouse, consisting of a production hall, an administration building, a dry warehouse, a deep-freeze warehouse, a technological building, a goods receiving department, and a warehouse for empties.
The entire object comprises approx. 63.000 sqm gross floor area.
The entire object comprises approx. 63.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-5 (LP4-5)
- Workshop Design for Precast Elements
- BIM Services
TESLA Gigafactory Berlin-Brandenburg
Grünheide, Germany
The object is the new construction of the water treatment (WWT), a wasteyard and a stamping facility of the Tesla Gigafactory Berlin-Brandenburg.
The entire object approx. 34.000 sqm gross floor area. Specifically, The WWT building comprises a ground floor and an upper floor with a GFA of 7.600 sqm. The wasteyard is a single story building with 7.900 sqm GFA. The stamping is a 18.500 sqm building.
The entire object approx. 34.000 sqm gross floor area. Specifically, The WWT building comprises a ground floor and an upper floor with a GFA of 7.600 sqm. The wasteyard is a single story building with 7.900 sqm GFA. The stamping is a 18.500 sqm building.
Services
- Structural Design, work stage 1-6 (LP1-6)
- Steel Structure Design
- Workshop Design for Precast Elements
- BIM Services
BER22 Data Center
Berlin, Germany
The object to be designed is a new construction a low-rise data center from Vantage Data Centers. The low-rise design consists of a data center building with an adjacent yard and is located next to BER21. The scope of this offer is the structure of the BER22. The building is about 82 m long, 79 m wide and 20 m high. The building consists of a ground floor, first floor and roof floor. Each floor measures about 6 m high. The main load bearing structure - floors, beams, columns and walls - is made of precast concrete elements. The foundation consists of single and strip foundations. Equipment supporting structures, e.g. the roof platform, are made from structural steel.
The entire object comprises approx. 18.000 sqm gross floor area.
The entire object comprises approx. 18.000 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
FR10 Data Center
Frankfurt, Germany
The project involves the construction of a new data center with an adjoining office/ storage area, a generator building and the construction of 23 parking spaces. The walls will be approximately 5m high with continuity reinforcement at intermediate levels. The buildings will be constructed 1 level at a time. The entire building consists of:
- The main building has a 3-storey non-roofed industrial building and an adjoining 4-storey office building in reinforced concrete and ground plan dimensions of approx. 55m x 61m. Above the data center is a 2-storey technical platform in steel construction.
- The generator building is a 3-storey building for emergency power generators and pump rooms with no basement in reinforced concrete. A technical platform in steel construction is planned on the roof.
- Adjoining tank facilities for diesel and sprinkler water
The foundation of entire building is built on an elastically bedded floor slab.
The entire object comprises approx. 16.880 sqm gross floor area.
The entire object comprises approx. 16.880 sqm gross floor area.
Services:
- Structural Design, work stage 5 (LP5)
- BIM Services
FR13 Data Center
Frankfurt, Germany
The object is a new construction of a low-rise data center from Vantage Data Centers. The low-rise design consists of a data center featuring several buildings. The scope of this project is the structure of FR13. The object FR13 is about 76 m long, 32 m wide and a maximum of 27m high.
The entire object comprises approx. 13.900 sqm gross floor area.
The entire object comprises approx. 13.900 sqm gross floor area.
Services
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
New construction of a Warehouse in Oederan
Oederan, Germany
Planning for the new construction of a warehouse in Oederan, Germany. The building has two stories and a social wing. The entire property has external dimensions of approx. 100.0m x 48.5m and the entire object comprises approx. 4.850 sqm gross floor area.
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
BER21 Data Center
Mittenwalde, Berlin-Brandenburg, Germany
Structural detailed design for the BER21 data center in Mittenwalde, Berlin. The low-rise design consists of two data centers BER21 A1 and A2. The data center campus is a 4.5 hectare site with a master plan for the construction of two buildings.
The entire object comprises approx. 14.900 sqm gross floor area.
The entire object comprises approx. 14.900 sqm gross floor area.
Services
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
BER13 Data Center
Uferring, Ludwigsfelde, Berlin, Germany
Structural detailed design for the BER13 data center in Uferring, Ludwigsfelde, Berlin. The object is a new low-rise data center construction by Vantage Data Centers. The low-rise design consists of a data center, referred to as BER13 in this example, and a yard.
The entire object comprises approx. 14.900 sqm gross floor area.
The entire object comprises approx. 14.900 sqm gross floor area.
Services:
- Structural Design, work stage 4-6 (LP4-6)
- Workshop Design for Precast Elements
- BIM Services
Extension of bakery Reimann
Dresden, Germany
Planning for the extension of the order picking place and warehouse of a bakery in Dresden, Germany. The building comprises of a ground floor, an upper floor, and an attic. The entire property has a GFA of around 5.200 sqm
Photo: Architecture Gallery Greven
Photo: Architecture Gallery Greven
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
New construction of bakery in Chemnitz
Chemnitz, Germany
The planning for the new construction of a bakery in Chemnitz, Germany. The bakery has the dimensions of approx. 61m x 49m, and the additional warehouse has the size of approx. 24m x 17m. The bakery/storage area is single-story, while other areas (office + social) are executed as two-story.
Photo: Schäfers Backstube GmbH
Photo: Schäfers Backstube GmbH
Services:
- Structural Design, work stage 5 (LP5)
- Workshop Design for Precast Elements
- BIM Services
New thermal power plant in Leipzig Süd
LEIPZIG, GERMANY
The planning of the new thermal power plant in Leipzig Süd, Germany (HKW Leipzig Süd). This project includes:
1. A power station building (55.8m x 40.3m)
2. A gas system building (31.8m x 24.0m)
3. A pump hall (42.5m x 24.5m).
The entire object comprises approx. 17.500 sqm gross floor area.
Photo: André Kempner/ Gaskraftwerk Süd
Photo: André Kempner/ Gaskraftwerk Süd
SERVICES:
- Structural Design, work stage 4-5 (LP4-5)
- Workshop Design for Precast Elements
- BIM Services
Khmer Beverages (KHB) factory
Phnom Penh, Cambodia
gbc engineers Cambodia has been chosen to perform structural survey and assessment of Khmer Beverages (KHB) factory in Phnom Penh.
Khmer Beverages is the leading producer of alcoholic and non-alcoholic drinks in Cambodia. The company plans to install solar panels on the existing building roofs of this facility. The installation is planned on 7 buildings, divided in 5 steel superstructures supported by reinforced concrete foundation and 2 reinforced concrete structures, with a total surface of approx. 40.000 sqm.
Khmer Beverages is the leading producer of alcoholic and non-alcoholic drinks in Cambodia. The company plans to install solar panels on the existing building roofs of this facility. The installation is planned on 7 buildings, divided in 5 steel superstructures supported by reinforced concrete foundation and 2 reinforced concrete structures, with a total surface of approx. 40.000 sqm.
Services:
- Roof Structural Review
- Structural Survey and Assessment
- Structural Survey and Assessment
Pepperl + Fuchs Greenfield Factory
Ho Chi Minh City, Vietnam
New construction of electronic sensors and components factory Pepperl+Fuchs (P+F). The project includes new warehouse, production facility, and multi storey motorbike parking. GFA is approx. 21.390 sqm.
Services:
- Structural Design Review Service, compliance with Eurocode and Good Engineering Practice (GEP
Total Cambodia - Odem Warehouse Expansion
Phnom Penh, Cambodia
Expansion of the TOTAL Cambodia S.A. Warehouse facility in Phnom Penh Odem, Cambodia.The entire object comprises approx. 1.880 sqm gross floor area.
Services:
- Topographic Survey and Geotechnical Investigations,
- Architectural, MEP, Civil and Structural Engineering Design
- Feasibility Studies, Concept and Detailed Design incl. Tendering
